Fully Enclosed Precision Linear Stage with Oil and Contamination Resistance
SEXGL Linear slide rail (also known as linear guideway) is a type of mechanical component that enables high-precision linear motion through rolling friction, and is widely used in industrial automation, precision manufacturing, medical equipment and other fields.
The linear slide rail is composed of a guide rail and a slider, and the rolling elements (such as balls and rollers) are used to roll between the guide rail and the slider in a circular manner, which converts the sliding friction into rolling friction and significantly reduces the friction coefficient.
Core Performance Parameters
1.High-Speed Operational Efficiency: Through innovative collaborative design of high-tension synchronous belts and precision guide rails, the maximum operating speed achieves three times that of traditional lead screw modules, making it significantly suitable for high-frequency operation scenarios such as high-speed sorting and handling.
2.Long-Stroke Expansion Capability: Supports customized R&D of special stroke modules, which can accurately adapt to long-stroke movement requirements and meet diverse industrial application scenarios.
3.Precision Positioning Function: With optimized tooth profile design and precision guide rail machining processes, it achieves ±0.1mm repeat positioning accuracy, ensuring the stability and reliability of high-precision operations.
4.Maintenance-Free Design Features: Adopts self-lubricating guide rails and fully sealed protective structures, eliminating the need for daily lubrication maintenance, significantly reducing equipment maintenance costs, and improving operation and maintenance efficiency.
| ※ | Basic specifications PTB22 |
|
| Specification | Repeatable positioning accuracy(mm) | ±0.08 |
| Lead (mm) | 40 |
| Max speed(mm/s) | 2000 |
| Max load(kg) | Horizontal | 85 |
| Vertical | - |
| Rated thrust(N) | 367 |
| standard stroke(mm) | 20-3500mm/50 interval |
| Component | AC servo motor capacity | 750 |
| Belt width | 45 |
| High rigidity linear slider | W23×H18 |
| Origin sensor Plug | PM-T45(NPN) |
|
|
Fully Enclosed Precision Linear Stage with Oil and Contamination Resistance Images
|
